| Size | Color | Height | Length (inches) | Width (inches) | Weight | Part # |
|---|---|---|---|---|---|---|
| 4″ 102mm | White | 9.0″ 229mm | 14.0″ 356mm | 14.0″ 356mm | 1.70lbs .74kg | 602-1405TPO |
| 5″ 127mm | White | 9.0″ 229mm | 15.0″ 381mm | 15.0″ 381mm | 2.20lbs .96kg | 602-1410TPO |
| 6″ 152mm | White | 9.0″ 229mm | 16.0″ 406mm | 16.0″ 406mm | 2.35lbs 1.02kg | 602-1415TPO |
| 7″ 178mm | White | 9.0″ 229mm | 17.0″ 432mm | 17.0″ 432mm | 2.70lbs 1.18kg | 602-1420TPO |
| 8″ 203mm | White | 9.0″ 229mm | 18.0″ 457mm | 18.0″ 457mm | 3.00lbs 1.31kg | 602-1425TPO |
| 9″ 229mm | White | 9.0″ 229mm | 19.0″ 483mm | 19.0″ 483mm | 3.50lbs 1.53kg | 602-1430TPO |
| 10″ 254mm | White | 9.0″ 229mm | 20.0″ 508mm | 20.0″ 508mm | 3.65lbs 1.59kg | 602-1435TPO |
| 11″ 279mm | White | 9.0″ 229mm | 21.0″ 533mm | 21.0″ 533mm | 4.05lbs 1.77kg | 602-1436TPO |
| 12″ 305mm | White | 9.0″ 229mm | 22.0″ 559mm | 22.0″ 559mm | 4.25lbs 1.85kg | 602-1440TPO |
• HOTWELD for torch-on and other applications.
• 4” 102mm roof flange.
• 8” 203mm height.
• Available in sizes one inch increment from 4″ to 12″.
• Custom sizes available by request.
• Menzies TPO Direct Weld™ for fast installation on TPO Roofing Systems.
042416
