| Size | Color | Weight | Part # |
|---|---|---|---|
| 2″ 51mm (1 3/4″ 44mm OD) | 5.25lbs 2.3kg | 300-3165TPO | |
| 3″ 76mm (2 3/4″ 70mm OD) | 5.95lbs 2.6kg | 300-3166TPO | |
| 4″ 102mm (3 3/4″ 95mm OD) | 6.50lbs 2.8kg | 300-3167TPO | |
| 6″ 152mm (5 3/4″ 146mm OD) | 6.65lbs 2.9kg | 300-3169TPO |
At Menzies Metal Products, we build many of our products in house at our Lower Mainland factory. This is why we’re able to provide optimal service for contractors that need specific measurements on their roof drains, deck drains, vents, flashings & building supplies.
• TPO coated flange.
• Clamping ring bolts down into compression fit mounting ring.
• Stainless steel screw fastens die-cast aluminum strainer.
• No vertical studs to interfere with membrane.
• Lower clamping ring mount is embedded in the drain bowl. No bolts penetrating drain body.
• Cast aluminum strainer.
• All fasteners are stainless steel.
• Listed to meet Canadian and U.S. standards by QAI. Meets CSA B272 and IAPMO PS 64.
• For complete seal assurance this product works best when used with Menzies Blue Drain Seal.
• Also available as No Hub outlet model.
• Longer pipes available.
